CLIMAX
Complete cloud solution for enterprise businesses
Overview
Our ClIMAX provides a comprehensive set of tools and services designed to transform your business operations. Built with scalability and security in mind, it offers seamless integration with existing systems while enabling future growth.
Key Features
Quick setup
Adhesive Installation
Flexible Application
Aesthetic Design
Applications
Commercial Buildings
Provides accurate temperature and humidity readings for both indoor and outdoor areas, aiding in monitoring air quality to meet green building certifications like WELL and BEAM.
Residential Buildings
Allows users to monitor temperature and humidity changes, enhancing HVAC system efficiency for energy savings.
Scientific Research
Measures wall temperature to monitor building heat absorption, assessing the performance of heat-resistant coatings by comparing external and internal wall data.
Specifications
Input Power
2pcs FR6AA 3.0V battery (5,800mAh)
Working Voltage
DC 2V – 3.5V
Standby Current
2uA / 3.0V
Low Voltage Threshold
2.4V
Battery Voltage Measurement Accuracy
±0.1V
Frequency Range
868MHz – 928MHz
Tx Power
US915: 20dbm, AS923: 16dbm, AU915: 20dbm, EU868: 16dbm
Receiving Sensitivity
US915: -136dBm, AS923: -126dBm, AU915: -136dBm, EU868: -126dBm
Antenna Type
Built-in antenna
Communication Distance
Up to 10km
Data Transfer Rate
0.3kbps – 50kbps
Modulation
LoRa/FSK (selectable)
Support Lorawan Bands
US915,AS923,AU915,EU868,KR920
Dimensions
100mm x 100mm x 25mm
Weight
150g
Operating Temperature
-40℃ – 115℃
Environmental Humidity Range
<100% RH (no condensation)
Storage Temperature
-55℃ – 125℃
Gallery
